CNC Milling machines

5 osni:

Axis - travel:

X - axis 820 mm

Y - axis 700 mm

Z - axis 450 mm

A - 230°(+/- 115°)

C - 360°

n=30.000 u/min

5 axes:

Axis - travel:

X - axis 550 mm

Y - axis 400 mm

Z - axis 300 mm

Table - size:

X - axis 650 mm

Y - axis 500 mm

n=42.000 u/min

3 axes:

X - axis 640 mm

Y - axis 600 mm

Z - axis 550 mm

n=12.000 u/min

3 axes:

x - axis 750 mm

Y - axis 600 mm

Z - axis 560 mm

n=28.000 u/min

Power: 15/10 kW

5 axes:

X - axis 1080 mm

Y - axis 710 mm

Z - axis 710 mm

B - axis (+12,5° - 91°)

B - axis (nx360°)

n=18.000 u/min

Power: 7,5 kW

3 axes:

X - axis 500 mm

Y - axis 300 mm

Z - axis 300 mm

Power: 5 kW

3 axes:

X - axis 500 mm

Y - axis 250 mm

Z - axis 160 mm

Power: 4 kW

3 axes:

X - axis 580 mm

Y - axis 295 mm

Z - axis 360 mm

Power: 2,5 kW

3 axes:

X - axis 290 mm

Y - axis 170 mm

Z - axis 310 mm
